API 602 Manual Forged Steel Flanged Bellow Seal Gate Valve

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
●Size: 1/2''-2''(DN15~DN50)
●Pressure Rating: 150LB-2500LB/PN16~PN160/10K~60K)Material:A105,LF2, LF3, F11, F22,F5,304(L),316(L), F347;F321; F51,Monel,Alloy.
Size:
Availability:
Quantity:
  • Forged Steel Gate Valve

  • J-VALVES

API 602 Manual Forged Steel Flanged Bellow Seal Gate Valve


● Valve alias: API 602 Manual Forged Steel Flanged Bellow Seal Gate Valve

Quick Detail:
● Size: 1/2''-2''(DN15~DN50)
● Pressure Rating: 150LB-2500LB/PN16~PN160/10K~60K)Material:A105,LF2, LF3, F11, F22,F5,304(L),316(L), F347;F321; F51,Monel,Alloy.
● Suitable Temperature: -29ºC~425ºC.
● Suitable Medium: Water, Steam, Oil and natural gas etc.

Description:
● Design and manufacture conformto:API602,BS5352,ANSI B16.34
● Socket welded dimension conform to ANSI B16.11,JB/T1751
● Screw ends dimension conform to ANSI B1.20.1,JB/T7306
● Butt-welded conform to ANSI B16.25,JB/T12224
● Flange ends conform to ANSI B16.5,JB79
● Test and inspection conform to:API598,GB/T13927,JB/T9092
● With sealing design, it is more safe and convenient to replace packing( Seat seal material could be decided by customer's request or according to valve's medium & temp. condition).
● Operation: Hand wheel, Gear,Pneumatic actuator & Electric Actuator.

Applications:
API 602 Manual Forged steel flanged bellow seal gate valve is used industrial and Oil/Gas piping applications requiring the higher flow capacity and lower pressure drop of full port internal flow-ways, and those applications where ease of repairability is desired.

Competitive Advantage:
● On Samples    Buyer bear the air fee, but this fee will be reduced from order directly
● On After Sales    Free replacement if there is any quality problem

● On Delivery    Never delay delivery time
● On Materials    Ensure material pure
● Ensure material pure

3

NPS

L

d

D

D1

D2

C

f

n-Ø

1/2"

140

10

95

66.7

34.9

12.7

2

4-16

3/4"

152

13.5

115

82.6

42.9

14.3

2

4-19

1"

165

18

125

88.9

50.8

15.9

2

4-19

1-1/4"

178

24

135

98.4

63.5

17.5

2

4-19

1-1/2"

190

29

155

114.3

73

19.1

2

4-22

2"

216

36.5

165

127

92.1

20.7

2

8-19

2-1/2"

241

45

190

149.2

104.8

23.9

2

8-22
