Product Introduction
Porduct Name | J-Valves Made in China 3PC Ball Valve Flange End Direct Mounting Pad 304/316 1000wog Ball Valve |
Material | 304/316/B62/2207/2507/316ti/C95800, etc. |
Size | 2"-24"(DN100-DN600) |
Port | Full Port |
Working Pressure | 150LB/300LB |
Connection Ends | RF |
Working Temp. | -20ºC~200ºC |
Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
Operated | Manual, Worm Gear, Pneumatic actuator, Electric Actuator |
Features | Investment casting,Blow-out proof stem,Anti-static device(option) |
Design standard | API6D/API608/API607 |
Inspection&Testing | According to API598 |
Brand | J-VALVES |
Advantages
Superior Material Quality
Constructed with 304/316 stainless steel, these ball valves offer excellent corrosion resistance. 304 stainless steel is highly resistant to general corrosion in a wide range of environments, making it suitable for applications where the valve may be exposed to moisture or mild corrosive substances. 316 stainless steel, on the other hand, contains molybdenum, which provides enhanced resistance to pitting and crevice corrosion, making it ideal for more aggressive chemical or marine environments.
High - Pressure Rating
With a 1000wog (working pressure of 1000 pounds per square inch water or gas) rating, these ball valves can handle high - pressure fluid systems with ease. This high - pressure capacity ensures reliable operation in industrial settings such as oil and gas pipelines, power plants, and chemical processing plants, where maintaining system integrity under high - pressure conditions is crucial.
Flange End Design
The flange end connection of these ball valves provides a secure and leak - tight joint. Flange connections are easy to install and maintain, as they allow for quick disassembly and reassembly when needed. This design also distributes stress evenly across the connection, reducing the risk of joint failure due to pressure or vibration.
Direct Mounting Pad
The direct mounting pad feature simplifies the installation process. It allows for easy attachment of actuators, such as electric or pneumatic actuators, without the need for additional mounting brackets or complex installation procedures. This not only saves installation time but also ensures accurate alignment of the actuator with the valve, leading to smooth and efficient operation.
Three - Piece Construction
The three - piece design of these ball valves offers several advantages. It allows for easy access to the internal components, such as the ball and seats, for maintenance and repair. In case of wear or damage to the internal parts, the valve can be disassembled quickly, and the affected components can be replaced without having to replace the entire valve, thus reducing maintenance costs.
Applications
Oil and Gas Industry
In oil and gas pipelines, these ball valves are used to control the flow of crude oil, natural gas, and refined petroleum products. Their high - pressure rating and corrosion - resistant materials make them suitable for handling the harsh conditions of the oil and gas industry, including high - pressure transportation and exposure to various chemical substances.
Power Generation
Power plants, whether they are coal - fired, gas - fired, or nuclear, use these ball valves in their cooling water systems, steam lines, and fuel supply systems. The 304/316 stainless steel construction can withstand the high - temperature and high - pressure environments in power plants, ensuring reliable operation and preventing leaks that could disrupt power generation.
Chemical Processing
In chemical plants, the J - Valves 3PC ball valves are used to control the flow of a wide variety of chemicals. The corrosion resistance of 304/316 stainless steel makes them suitable for handling both acidic and alkaline chemicals. They can be used in processes such as chemical synthesis, distillation, and storage tank isolation.
Marine Applications
On ships and offshore platforms, these ball valves are used in seawater cooling systems, fuel lines, and ballast water systems. The 316 stainless steel option, with its enhanced resistance to marine corrosion, ensures long - term reliable operation in the harsh saltwater environment.
Industrial Water Systems
In industrial water treatment plants and water distribution systems, these ball valves are used to control the flow of water. Their ability to provide a tight shut - off and withstand the pressure in water systems makes them an ideal choice for applications such as water intake, filtration, and water recycling processes.
Product Introduction
Porduct Name | J-Valves Made in China 3PC Ball Valve Flange End Direct Mounting Pad 304/316 1000wog Ball Valve |
Material | 304/316/B62/2207/2507/316ti/C95800, etc. |
Size | 2"-24"(DN100-DN600) |
Port | Full Port |
Working Pressure | 150LB/300LB |
Connection Ends | RF |
Working Temp. | -20ºC~200ºC |
Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
Operated | Manual, Worm Gear, Pneumatic actuator, Electric Actuator |
Features | Investment casting,Blow-out proof stem,Anti-static device(option) |
Design standard | API6D/API608/API607 |
Inspection&Testing | According to API598 |
Brand | J-VALVES |
Advantages
Superior Material Quality
Constructed with 304/316 stainless steel, these ball valves offer excellent corrosion resistance. 304 stainless steel is highly resistant to general corrosion in a wide range of environments, making it suitable for applications where the valve may be exposed to moisture or mild corrosive substances. 316 stainless steel, on the other hand, contains molybdenum, which provides enhanced resistance to pitting and crevice corrosion, making it ideal for more aggressive chemical or marine environments.
High - Pressure Rating
With a 1000wog (working pressure of 1000 pounds per square inch water or gas) rating, these ball valves can handle high - pressure fluid systems with ease. This high - pressure capacity ensures reliable operation in industrial settings such as oil and gas pipelines, power plants, and chemical processing plants, where maintaining system integrity under high - pressure conditions is crucial.
Flange End Design
The flange end connection of these ball valves provides a secure and leak - tight joint. Flange connections are easy to install and maintain, as they allow for quick disassembly and reassembly when needed. This design also distributes stress evenly across the connection, reducing the risk of joint failure due to pressure or vibration.
Direct Mounting Pad
The direct mounting pad feature simplifies the installation process. It allows for easy attachment of actuators, such as electric or pneumatic actuators, without the need for additional mounting brackets or complex installation procedures. This not only saves installation time but also ensures accurate alignment of the actuator with the valve, leading to smooth and efficient operation.
Three - Piece Construction
The three - piece design of these ball valves offers several advantages. It allows for easy access to the internal components, such as the ball and seats, for maintenance and repair. In case of wear or damage to the internal parts, the valve can be disassembled quickly, and the affected components can be replaced without having to replace the entire valve, thus reducing maintenance costs.
Applications
Oil and Gas Industry
In oil and gas pipelines, these ball valves are used to control the flow of crude oil, natural gas, and refined petroleum products. Their high - pressure rating and corrosion - resistant materials make them suitable for handling the harsh conditions of the oil and gas industry, including high - pressure transportation and exposure to various chemical substances.
Power Generation
Power plants, whether they are coal - fired, gas - fired, or nuclear, use these ball valves in their cooling water systems, steam lines, and fuel supply systems. The 304/316 stainless steel construction can withstand the high - temperature and high - pressure environments in power plants, ensuring reliable operation and preventing leaks that could disrupt power generation.
Chemical Processing
In chemical plants, the J - Valves 3PC ball valves are used to control the flow of a wide variety of chemicals. The corrosion resistance of 304/316 stainless steel makes them suitable for handling both acidic and alkaline chemicals. They can be used in processes such as chemical synthesis, distillation, and storage tank isolation.
Marine Applications
On ships and offshore platforms, these ball valves are used in seawater cooling systems, fuel lines, and ballast water systems. The 316 stainless steel option, with its enhanced resistance to marine corrosion, ensures long - term reliable operation in the harsh saltwater environment.
Industrial Water Systems
In industrial water treatment plants and water distribution systems, these ball valves are used to control the flow of water. Their ability to provide a tight shut - off and withstand the pressure in water systems makes them an ideal choice for applications such as water intake, filtration, and water recycling processes.
1.Design & Manufacture standard:API600
2.Pressure & Temperature standard:ASME B16.25
3.Face to face dimension standard: ASME B16.10
4.Ends Connection standard:ASME B16.5
5.Test & Inspect standard: API598
Design & Manufacture standard | ASME B16.34 |
Pressure & Temperature standard | ASME B16.34 |
Face to face dimension standard | MFG Standard |
Ends Connection standard | ASME B1.20.1 |
Test & Inspect standard | API 598 |
Testing Pressure(Mpa)
Pressure | 150LB | 300LB | 600LB | 900LB | 1500LB | 2500LB | |
Strength Testing | 3.0 | 7.5 | 15.4 | 23.0 | 37.5 | 63.0 | Mpa |
Seal Testing | 2.2 | 5.5 | 11.2 | 16.9 | 27.5 | 46.2 | |
Air Testing | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
Design & Manufacture standard | ASME B16.34 |
Pressure & Temperature standard | ASME B16.34 |
Face to face dimension standard | MFG Standard |
Ends Connection standard | ASME B1.20.1 |
Test & Inspect standard | API 598 |
Testing Pressure(Mpa)
Pressure | 150LB | 300LB | 600LB | 900LB | 1500LB | 2500LB | |
Strength Testing | 3.0 | 7.5 | 15.4 | 23.0 | 37.5 | 63.0 | Mpa |
Seal Testing | 2.2 | 5.5 | 11.2 | 16.9 | 27.5 | 46.2 | |
Air Testing | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
