2PC Flange Stainless Steel JIS 10K Floating Ball Valve

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
The J-VALVES Style Split-Body full port flanged end ball valves employ investment or shell cast bodies & tailpieces, all produced from ASTM grade materials that are properly heat treated and chemically finished. All wall thicknesses comply with JIS B2073 2083 as do bolting stress levels.

Industrial and Oil/Gas piping applications requiring the higher flow capacity and lower pressure drop of full port internal flow-ways, and those applications where ease of repairability is desired.

Floating Ball Valves are designed, constructed, and tested according to JIS Standards. Other international standards including API ASME ANSI BS and DIN are also available upon request.
Availability:
Quantity:
  • 1/2“-10”

  • J-VALVES

2PC Flange Stainless Steel JIS 10K Floating Ball Valve

1. 2PC Flange Stainless Steel JIS 10K Floating Ball Valve Technical specifications:

2-Piece Bolted Body, Full Port Construction

Fully Compliant to JIS B2073 2083

Fully Compliant to JIS B2071 2081

Submerged Packing System & Direct Mount Actuation

Standard ISO Actuator Mounting Pads on All Sizes

Standard Locking Stainless Steel Handles

Second Generation PTFE Seats Provide Higher Operating Temperatures

Standard Electrically Grounded Ball & Stem



2. 2PC Flange Stainless Steel JIS 10K Floating Ball Valve  Product Specification:

Size: 1/2''-10''(DN15~DN250)

Pressure Rating: 150LB-600LB/PN16~PN100/10K~60K)

Material: A351 CF8M/CF8/CF3/CF3M, A216 WCB, A352 LCB/LCC,F51/F53/C95800

Suitable Temperature: -196ºC~450ºC( Different temperature choose different materials).

Suitable Medium: Water, Steam, Oil and natural gas etc.



3.  2PC Flange Stainless Steel JIS 10K Floating Ball Valve  Product Feature:

Floating ball, full bore or reduce bore.

ISO5211 mounting pad for option.

Blow-out proof stem design.

PTFE/RPTFE seat seal( Seat seal material could be decided by customer's request or according to valve's medium & temp. condition).

Anti-static design and API 607 Fire Safe Design available

l   Operation: Hand wheel, Worm wheel, Pneumatic actuator & Electric Actuator.



4. 2PC Flange Stainless Steel JIS 10K Floating Ball Valve  Product Drawing:


Note: All the data should be confirmed with the approved drawings of manufacturer.



Tips:

     We also manufacture other type valves, as butterfly valve, check valve, globe valve, Y strainer, sanitary butterfly valve, sanitary ball and so on.

     Any item meets your interest, anything confused you, pls keep me posted, let's talk more.
