Understanding Gate Valve Sealing Structures
• Tapered Disc: The wedge gate valve features a tapered disc that fits snugly against the seat when closed, providing a tight seal.
• Pressure-Enhanced Sealing: The pressure of the fluid helps to push the disc against the seat, enhancing the sealing performance.
• Self-Aligning: The wedge design allows for self-aligning of the disc, ensuring consistent contact with the seat.
• High-Pressure Applications: Wedge gate valves are well-suited for high-pressure applications due to their ability to withstand significant mechanical stresses.
• Reliable Sealing: The pressure-enhanced sealing mechanism ensures a tight seal, minimizing the risk of leaks.
• Durability: The robust design and self-aligning feature contribute to the valve's long-term reliability.
• Parallel Disc: The parallel gate valve features a flat disc that moves vertically to control the flow. The disc is parallel to the seat, providing a tight seal when closed.
• Uniform Sealing Pressure: The parallel design ensures uniform sealing pressure across the entire seat, reducing the risk of uneven wear.
• Ease of Maintenance: The simpler design makes parallel gate valves easier to maintain and repair.
• Low Torque Operation: Parallel gate valves require less torque to operate, making them suitable for applications where manual operation is preferred.
• Uniform Sealing: The parallel design ensures consistent sealing pressure, reducing the risk of leaks and extending the service life of the valve.
• Simplicity: The straightforward design makes parallel gate valves easier to install, maintain, and repair.
Comparative Analysis: Wedge vs. Parallel Gate Valves
| Feature | Wedge Gate Valves | Parallel Gate Valves |
| Sealing Mechanism | Pressure-enhanced sealing with a tapered disc | Uniform sealing pressure with a parallel disc |
| Leakage Risk | Low, due to pressure-enhanced sealing | Slightly higher, especially in high-pressure applications |
| Suitable Applications | High-pressure applications, oil and gas, power generation | Lower pressure applications, water treatment, HVAC systems |
| Feature | Wedge Gate Valves | Parallel Gate Valves |
| Maintenance | More complex design, potentially higher maintenance | Simpler design, easier to maintain and repair |
| Service Life | Long service life due to robust design | Long service life with proper maintenance |
