Overview of ANSI, DIN, and JIS Standards
ANSI standards for check valves are primarily governed by the American Society of Mechanical Engineers (ASME) and the American Petroleum Institute (API). Key standards include:
• ASME B16.34: This standard covers the design, materials, and testing of valves, including check valves, with flanged, threaded, and welded ends.
• API 594: This standard specifically addresses wafer and double-flanged check valves, providing detailed requirements for design, materials, and testing.
• API 6D: This standard is applicable to pipeline valves, including check valves, and covers design, materials, testing, and marking requirements.
DIN standards are developed by the German Institute for Standardization and are widely used in Europe and globally. Key standards for check valves include:
• DIN 3356: This standard covers the design, materials, and testing of check valves, including lift check valves and swing check valves.
• DIN EN 13709: This standard addresses industrial valves, including steel globe and globe stop and check valves, covering design, materials, and testing requirements.
• DIN EN 16767: This standard focuses on metal check valves, providing detailed requirements for design, materials, and performance.
JIS standards are developed by the Japanese Industrial Standards Committee and are widely used in Japan and other Asian countries. Key standards for check valves include:
• JIS B2074: This standard covers the design, materials, and testing of check valves, including lift check valves and swing check valves.
• JIS B2002: This standard addresses the structural length of valves, ensuring compatibility and interchangeability.
• JIS B2003: This standard covers the pressure testing requirements for valves, including check valves.
| Feature | ANSI | DIN | JIS |
| Design Philosophy | Focus on high-pressure and high-temperature applications, with detailed requirements for materials and testing. | Emphasis on precision engineering and compatibility with European systems. | Designed for a wide range of applications, with a focus on reliability and durability. |
| Materials | Common materials include carbon steel, stainless steel, and alloy steel. | Similar materials used, with additional emphasis on specific alloys for high-performance applications. | Materials include carbon steel, stainless steel, and other alloys, with specific requirements for corrosion resistance. |
| Manufacturing Tolerances | Tight tolerances to ensure high performance and reliability. | Very precise tolerances, ensuring high precision and compatibility. | Moderate tolerances, balancing performance and cost-effectiveness. |
| Feature | ANSI | DIN | JIS |
| Testing Standards | ASME B16.34, API 594, API 6D | DIN EN 13709, DIN EN 16767 | JIS B2074, JIS B2003 |
| Pressure Testing | Detailed requirements for hydrostatic and pneumatic testing, ensuring valves can withstand rated pressures. | Comprehensive testing procedures, including hydrostatic and pneumatic tests, with specific requirements for different materials. | Pressure testing requirements aligned with international standards, ensuring reliability and safety. |
| Leakage Testing | Stringent leakage testing to ensure zero leakage under specified conditions. | Similar stringent testing to ensure no leakage under operating conditions. | Leakage testing aligned with international standards, ensuring high reliability. |
| Feature | ANSI | DIN | JIS |
| High-Pressure Applications | Suitable for high-pressure applications, commonly used in oil and gas, power generation, and chemical industries. | Also suitable for high-pressure applications, widely used in European industrial systems. | Suitable for a wide range of pressures, commonly used in chemical, petrochemical, and general industrial applications. |
| High-Temperature Applications | Designed to handle high temperatures, making them suitable for steam systems and other high-temperature processes. | High-temperature applications are also covered, with specific materials and designs to handle extreme temperatures. | Suitable for high-temperature applications, with materials and designs tailored to meet industry needs. |
| Corrosive Environments | Materials and coatings are selected to resist corrosion, making them suitable for chemical and petrochemical applications. | Similar focus on corrosion resistance, with specific alloys and coatings to handle corrosive fluids. | Designed to handle corrosive environments, with materials and coatings selected for durability. |
