Seawater destroys valve materials by at least four separate mechanisms, and an alloy chosen to beat one often loses to another. Chloride pitting starts on a passive film at a temperature and potential the alloy cannot hold. Crevice corrosion starts under a gasket, a seat ring or a fouling layer, where oxygen is consumed and cannot be replenished. Erosion-corrosion strips the film mechanically at a velocity the alloy cannot sustain, and it is the mechanism that ends most bronze valves. Galvanic corrosion appears wherever two materials of different potential share an electrolyte.
Add microbiologically influenced corrosion in stagnant lines and sulphide attack in polluted harbours, and the picture is complete. No single alloy beats all of them, so the selection starts from the duty; that is why the special material valves range exists rather than one grade sold for every marine job.
Nickel aluminium bronze to ASTM B148 C95800 is the workhorse of seawater valves: castable, repairable by welding, resistant to impingement. It holds up in moving seawater and fails where the film cannot reform, which means sustained high velocity, turbulence at a part-open seat, entrained sand, or sulphide-polluted water. 90/10 cupronickel tolerates higher velocity and more sulphide, which is why it appears in condenser circuits, but it is softer and costs more.
The failure to avoid is brass. Dezincification pulls the zinc out and leaves a copper sponge that looks sound and holds nothing, so a brass valve in seawater is a scheduled replacement, not a saving.
Austenitic 316 pits and crevices in ambient seawater, and passivation does not change that, because the molybdenum content sits below the threshold the chloride level demands. The number used to rank candidates is the pitting resistance equivalent number, and NORSOK M-001 sets the bar at 40 or above for stainless steels in seawater. Duplex 2205 comes in below that line, super duplex 2507 clears it, and the 6Mo super austenitics fill the space between duplex and the nickel alloys.
Duplex brings a second property that matters on a body: yield strength roughly double that of 316, so a high pressure body can be thinner and a stem smaller for the same torque. What it does not bring is unlimited temperature, because duplex embrittles above the range ASME permits. Our note on the ASTM A890 Grade 5A duplex gate valve covers how the ferrite balance is held in a casting.
Monel 400 is the answer when the water is fast, warm and clean, such as high velocity seawater, brine and marine pump discharge, because it resists impingement better than any bronze and has no chloride stress corrosion cracking threshold there. Its weaknesses are cost and galvanic behaviour: coupled to carbon steel it becomes a large noble cathode, and in stagnant crevices it can still suffer. Monel valves need the insulation kit as much as the alloy.
Inconel 625 and the Hastelloy C family extend the envelope to chlorinated seawater, oxidising conditions and higher temperature, and they appear where a firewater system must open after years of inactivity; Hastelloy valves are also the practical answer when seawater carries acid or hypochlorite. Titanium is the last step: immune at any velocity, but costly, prone to galling at the seat, and intolerant of careless coupling under cathodic protection, so titanium alloy valves belong where life and weight dominate the budget.
| Material | Main risk in seawater | Velocity tolerance | Relative cost | Where it fits |
|---|---|---|---|---|
| C95800 nickel aluminium bronze | Erosion-corrosion, sulphide attack | Moderate | Low | Cooling water, general marine duty |
| 90/10 cupronickel | Erosion at very high velocity, softness | Moderate to high | Medium | Condenser and cooling circuits |
| 316 stainless steel | Pitting and crevice corrosion | Low | Low | Not for seawater wetted parts |
| Duplex 2205 | Crevice corrosion in stagnant water | High | Medium | Brackish and treated seawater |
| Super duplex 2507 | Crevice in poorly flushed cavities | High | Medium to high | Continuous seawater, topside piping |
| Monel 400 | Galvanic couple, stagnant crevice | Very high | High | High velocity pumps and brine |
| Inconel 625, Hastelloy C | Cost, and little else | Very high | Very high | Chlorinated, oxidising, hot seawater |
| Titanium Grade 2 | Galling at the seat, hydrogen uptake | Very high | High | Firewater, long life, weight critical |
A super duplex valve between carbon steel flanges is a small cathode facing a large anode, and the pipe pays at the joint. Insulating gaskets and bolt sleeves break the path; coating alone does not. Under cathodic protection, overprotection generates hydrogen that can blister elastomer seats and embrittle a high strength stem, so material and protection design are reviewed together.
Four checks carry most of the risk. Positive material identification on every pressure retaining part catches a substituted grade before hydrotest. ASTM G48 Method A pitting and crevice testing on a coupon from the same heat proves the real corrosion resistance. For duplex, ASTM A923 covers the intermetallic phase check, and ferrite content is verified to the range agreed on the order. The EN 10204 3.1 material certificates, with heat numbers traceable to the castings, are what a marine surveyor actually reads.
Six lines prevent most disputes: the alloy with its UNS number rather than a trade name, the chloride level and maximum temperature, the flowing velocity and whether the line can stand stagnant, the test schedule including G48 and the ferrite range, the documentation level, and whether insulating kits are in scope for dissimilar flanges. Add the sealing principle to that list, because a correct alloy behind a sleeve that cannot take the temperature still leaks; the trade-off between lubricated versus sleeved plug valves applies to marine loading arms as much as to any other line.
Is duplex stainless steel suitable for seawater? Partly. Duplex 2205 falls below the pitting resistance equivalent number of 40 that NORSOK M-001 requires for stainless steels in seawater, so it is marginal in warm or stagnant chloride service and should not be used in a poorly flushed cavity. Super duplex 2507 clears the same threshold and is the duplex grade to specify for continuous seawater, with ferrite balance and intermetallic content verified on the casting.
What is the best valve material for seawater? There is no single best grade, because four mechanisms compete. Nickel aluminium bronze C95800 is the economical choice at moderate velocity, super duplex 2507 covers continuous seawater and higher velocity, Monel 400 covers fast warm clean seawater and brine, and titanium covers the cases where life and weight outweigh cost. Insulation between dissimilar flanges and stagnation risk decide whether the chosen grade survives.
Does 316 stainless steel work in seawater? No, not as a wetted material. The molybdenum content is too low to hold the passive film against chloride at ambient temperature, so 316 pits and crevices in quiet seawater and in splash zones alike. Passivation does not raise that threshold. Use 316 for the outside of a valve that never sees seawater, and choose bronze, super duplex or a nickel alloy for anything the water touches.
