Flat seals, as the name suggests, utilize a flat surface to create a seal between the valve disc and the seat. This design is relatively simple and straightforward, making it cost-effective and easy to manufacture. Here are some key technical features of flat seals:
• Surface Area: Flat seals have a larger contact area compared to conical seals. This can be advantageous in applications where a broad sealing surface is required.
• Ease of Manufacturing: The simplicity of the flat seal design makes it easier to produce and maintain. This can lead to lower costs and quicker production times.
• Material Compatibility: Flat seals can be made from a variety of materials, including metals and non-metals, depending on the application requirements. This flexibility allows for customization to suit specific needs.
• Sealing Pressure: Flat seals generally require higher sealing pressures to achieve a tight seal. This is because the larger contact area distributes the sealing force over a wider region, necessitating greater pressure to ensure effective sealing.
• Wear and Tear: Due to the larger contact area, flat seals may experience more wear and tear over time. This can lead to a gradual degradation of the sealing performance, requiring more frequent maintenance and replacement.
• Sensitivity to Contaminants: Flat seals are more sensitive to contaminants in the fluid. Particles can easily get trapped between the flat surfaces, leading to leaks and reduced sealing efficiency.
Conical seals, on the other hand, use a conical surface to create a seal. This design is more complex than that of flat seals but offers several advantages in terms of sealing performance. Key technical features of conical seals include:
• Conical Surface: The conical shape allows for a more focused sealing force, which can result in better sealing performance with lower sealing pressures.
• Self-Aligning Capability: Conical seals have a natural self-aligning feature, which helps to maintain proper contact between the disc and the seat even if there are slight misalignments.
• Material Options: Similar to flat seals, conical seals can also be made from a variety of materials, including stainless steel, brass, and various plastics, depending on the application requirements.
• Sealing Pressure: Conical seals typically require lower sealing pressures to achieve a tight seal. The conical shape focuses the sealing force more effectively, allowing for better sealing performance with less pressure.
• Wear Resistance: The focused sealing force also means that conical seals experience less wear and tear over time. This can lead to a longer service life and reduced maintenance requirements.
• Contaminant Resistance: Conical seals are less sensitive to contaminants in the fluid. The conical shape helps to prevent particles from getting trapped between the sealing surfaces, reducing the risk of leaks and maintaining sealing efficiency.
| Feature | Flat Seals | Conical Seals |
| Sealing Pressure | Higher | Lower |
| Wear Resistance | Lower | Higher |
| Contaminant Resistance | Lower | Higher |
| Self-Aligning Capability | None | Present |
| Feature | Flat Seals | Conical Seals |
| Cost | Lower | Higher |
| Complexity | Lower | Higher |
| Customization | High | High |
| Suitable Applications | General-purpose applications, applications with lower pressure requirements | High-pressure applications, applications with higher sealing demands |
