Understanding Globe Valve Internals
Globe valves consist of several key internal components, including the valve seat, stem, disc, and other sealing elements. These components are in direct contact with the fluid and are therefore susceptible to corrosion, wear, and other forms of degradation. The choice of materials for these components must be carefully considered based on the specific characteristics of the fluid being handled.
Common Corrosive Media and Suitable Materials
Characteristics: Water and steam are common media in many industrial applications. While water is generally considered non-corrosive, it can become corrosive when contaminated with impurities or when operating under high-temperature conditions.
• Stainless Steel (304, 316): Stainless steel is highly resistant to corrosion in water and steam applications. Grade 316 stainless steel, in particular, offers superior resistance to pitting and crevice corrosion.
• Nickel Alloys (Inconel, Hastelloy): For high-temperature steam applications, nickel alloys provide excellent resistance to oxidation and corrosion.
• Brass and Bronze: These materials are suitable for lower-pressure water applications but may not be ideal for high-temperature steam.
2. Acidic Solutions (e.g., Hydrochloric Acid, Sulfuric Acid)
Characteristics: Acidic solutions are highly corrosive and can rapidly degrade many common materials. The type and concentration of the acid, as well as the operating temperature, significantly influence the choice of materials.
• Hastelloy C: This nickel-molybdenum alloy offers excellent resistance to a wide range of acids, including hydrochloric and sulfuric acids.
• Tantalum: Tantalum is highly resistant to most acids, making it suitable for severe acid environments.
• PTFE (Polytetrafluoroethylene): PTFE is an excellent choice for sealing elements due to its chemical inertness and low friction properties.
3. Saline Solutions (e.g., Seawater)
Characteristics: Saline solutions, such as seawater, are highly corrosive due to the presence of chlorides. The choice of materials must consider both corrosion resistance and mechanical strength.
• Duplex Stainless Steel (2205, 2507): Duplex stainless steels offer excellent resistance to chloride-induced corrosion and stress corrosion cracking.
• Super Austenitic Stainless Steel (904L): This high-nickel, high-molybdenum alloy provides superior resistance to chloride corrosion.
• Titanium: Titanium is highly resistant to seawater corrosion and is often used in marine applications.
Factors Influencing Material Selection
The primary consideration in selecting materials for globe valve internals is their resistance to the specific corrosive media. Materials must be chosen based on their ability to withstand chemical attack, pitting, and crevice corrosion.
The operating temperature and pressure of the fluid system significantly influence material selection. Materials must be able to maintain their mechanical properties and corrosion resistance under the specified operating conditions.
The mechanical strength of the materials is crucial, especially for components that experience mechanical stress, such as the valve stem and disc. Materials must be strong enough to withstand the forces exerted during operation.
