Stainless Steel Three-Piece High-Platform Quick-Installation Ball Valve
Stainless Steel 3PC High-Platform Ball Valve Technical Parameters
Size Range: 1/2” ~ 4”
Working Temperature: -20°C ~ 280°C
Nominal Pressure: The common nominal pressure ratings are ≤PN16.
Applicable Media: It is suitable for a wide variety of media such as water, oil, steam, air, gases, petroleum, petrochemical products, and corrosive substances.
Stainless Steel 3PC High-Platform Ball Valve Product Features
High-Quality Material: The main body is made of stainless steel, such as the commonly used 304 or 316 stainless steel, which has good corrosion resistance and high-temperature resistance. It can adapt to various harsh working environments and prolong the service life of the valve.
High-Platform Design: The unique high-platform structure ensures the precise alignment of the valve stem and the actuator, facilitating the direct installation of pneumatic, electric or hydraulic actuators to achieve automated control, improving work efficiency and the accuracy of operation.
Quick Installation: The three-piece structural design makes the installation process of the valve simpler and faster. There is no need for complicated tools or tedious steps, which greatly saves installation time and cost and speeds up the project progress.
Excellent Sealing Performance: Advanced sealing technologies are adopted, such as using high-quality sealing materials like PTFE, ensuring the sealing reliability of the valve under various working conditions, effectively preventing medium leakage and guaranteeing the safe operation of the system.
Flexible Operation: It is usually equipped with a manual operating handle with an operating angle of 90°. The operation is simple and labor-saving. Meanwhile, electric or pneumatic actuators can also be configured according to needs to achieve remote control and automated operation.
Large Flow and Low Flow Resistance: The flow channel diameter of the ball valve is basically the same as the inner diameter of the pipeline. When the medium flows through, the resistance is small and the flow is large, which can ensure the efficient operation of the pipeline system and reduce energy consumption.
Stainless Steel 3PC High-Platform Ball Valve Application Fields
Petroleum Industry: Used in various pipeline systems during the processes of oil extraction, transportation and refining to control the flow of petroleum and its derivative products.
Chemical Industry: In the chemical production process, it is used to control the transportation and reaction processes of various chemical media to ensure the smooth progress of chemical production.
Metallurgical Industry: Applied to the control of gas and liquid media in the metallurgical process, such as the transportation and distribution of blast furnace gas, oxygen, etc.
Light Industry: In industries such as papermaking and food processing, it is used to control media such as water, steam, and air to ensure the stable operation of the production process.
Power Station: In the cooling water system, steam system and other pipelines of the power station, it is used to control the flow and pressure of media to ensure the safe operation of the power station.
Refrigeration Industry: Used in the refrigerant pipelines of the refrigeration system to control the flow of the refrigerant and achieve the efficient operation of the refrigeration system.
Stainless Steel 3PC High-Platform Ball Valve Maintenance and Service
Regular Inspection: Regularly check the sealing performance of the valve, the tightness of the connecting bolts and the working state of the actuator, and discover and deal with potential problems in a timely manner.
Cleaning and Maintenance: Regularly clean the valve to remove dust, dirt and rust on the surface, keeping the appearance of the valve clean and in good working condition.
Lubrication Maintenance: Regularly lubricate the moving parts such as the valve stem to reduce friction and prolong the service life of the valve.
Avoid Overloading: During the operation process, avoid exceeding the rated pressure and temperature range of the valve to prevent the valve from being damaged.
Stainless Steel 3PC High-Platform Ball Valve Packaging and Transportation
Packaging: Professional packaging methods are adopted, such as packaging with polyethylene bags, cartons or wooden boxes to ensure that the valve will not be damaged during transportation.
Transportation: During transportation, violent vibration and collision should be avoided to prevent the valve from being deformed or damaged. Meanwhile, moisture-proof and rain-proof measures should be taken to ensure that the performance of the valve will not be affected.
